RSL #4 Photo Gallery

RSL #4 Photo Gallery

• 001 : USGS aerial photo of RSL #4.
  • (390 x 293 = 11k) (800 x 600 = 29k) 001717


• 002: RSL #4 access road looking south at the turn off (1999).
  • The intake / exhaust ports for the underground generators are visible in the distance on the right.
  • (455 x 294 = 17k) (895 x 579 = 48k) 001013


• 003 : Wide view of RSL #4 looking southwest from the access road (1999).
  • Left: Limited area sentry station (LASS).
    Center: Underground remote launch operations building (RLOB).
    Right: white cap-like tops of Sprint launch cells.
  • (450 x 293 = 18k) (894 x 582 = 60k) 001009


• 004: Sprint launch cells from the access road (1999).
  • The exclusion area sentry station (EASS) that enforced the two man rule for the missile field has been removed.
  • (450 x 293 = 22k) (888 x 578 = 67k) 001012


• 005 : Closer view of RSL #4 from the access road on a foggy, frosty fall morning (1999).
  • Left: Limited area sentry station (LASS).
    Center: Remote launch operations building (RLOB).
    Right: white cap-like tops of Sprint launch cells are barely visible.
  • (440 X 294 = 27k) (882 x 589 = 98k) 001023


• 006: Early morning photo of the limited area sentry station (LASS) and remote launch operations building (RLOB) (1999).
  • (450 x 293 = 20k) (895 x 582 = 69k) 001022


• 007 : RSL #4 gate on a foggy, frosty fall morning (1999).
  • (440 x 293 = 25k) (890 x 592 = 87k) 001021


• 008 : Closeup of Sprint launch cells from the gate to RSL #4 (1999).
  • (450 x 292 = 19k) (898 x 582 = 59k) 001003
